• Metalux OHBL-72SE-MCL-UNV-L840-EL20W-CD-U 4' LED High Bay, 72000 Lumens, Standard Efficacy, Medium Clear Distribution, 120-277V, 80 CRI, 4000K, Emergency Battery Pack, 0-10V Dim
  • Metalux OHBL-72SE-MCL-UNV-L840-EL20W-CD-U 4' LED High Bay, 72000 Lumens, Standard Efficacy, Medium Clear Distribution, 120-277V, 80 CRI, 4000K, Emergency Battery Pack, 0-10V Dim
1 2

Metalux OHBL-72SE-MCL-UNV-L840-EL20W-CD-U 4' LED High Bay, 72000 Lumens, Standard Efficacy, Medium Clear Distribution, 120-277V, 80 CRI, 4000K, Emergency Battery Pack, 0-10V Dim

Metalux OHBL-72SE-MCL-UNV-L840-EL20W-CD-U 4' LED High Bay, 72000 Lumens, Standard Efficacy, Medium Clear Distribution, 120-277V, 80 CRI, 4000K, Emergency Battery Pack, 0-10V Dim

Price: $1,513.31
Price: $1,513.31

MODEL: Metalux-OHBL-1298

Usually Ships in 4-6 business days. Urgent Project? Contact Us
Add To Wishlist
Request a Quote
Ordering a large quantity?Request a quote
View full details

description

PRODUCT FAMILY SPECIFICATIONS
Construction
  • Rugged and durable scalable design with rigid, steel center channel
  • Mechanically attached end caps provide strength and durability
  • Suspension mounting with optional wire hook and chain set or cable; Single monopoint mounting with SPM tong hanger
Electrical
  • Long-Life LED system coupled with electrical driver for optimal performance
  • LED’s available in 3000K, 3500K, 4000K and 5000K with 70 CRI, 80 CRI and 90 CRI options
  • Electronic drivers are available for 120-277V, 347V and 480V applications
  • 0-10V dimming control (standard)
  • Operating temperature of -40 degrees C to 55 degrees C (refer to chart)
Emergency Battery Pack Option
  • 20-watt, 120-277V integral emergency battery pack available to meet critical life-safety lighting requirements
  • 90-minute batteries provide constant power to the LED system, ensuring code- compliance
  • Emergency/generator transfer options available (see ordering information for details)
Optics
  • Precision designed optics deliver even illumination
  • Offered in narrow, medium and wide distributions
Shielding
  • Standard lensing provides additional LED protection and optical control
  • Optional wire guards available for more complex environments
Controls
  • Wavelinx Lite Wireless sensor suitable for High bay applications up to 40ft (45ft major motion). Dual purpose, out of the box functionality with Occupied to Full, Unoccupied to 10%, and daylighting disabled.
Finish
  • White enamel finish preceded by a multistage cleaning cycle
  • Iron phosphate coating with rust inhibitor protects against contaminants and oxidation
Compliance
  • cULus listed for damp locations
  • LED modules comply with IESNA LM-79 and LM-80 standards
  • DesignLights Consortium Qualified and classified for both DLC Standard and DLC Premium (refer to www.designlights.org for details)
Warranty
  • Five year warranty standard.
