Portfolio LDSQ4D10X9030D010SQW1H 4" LED Precision High Center Beam Square Downlight, 1000 Lumens, No Optic, 90 CRI, 3000K, 120-277V, 0-10V Dim to 1%, 45 Degrees Cutoff, Self-Flanged Trim, Semi-Specular Finish
Portfolio LDSQ4D10X9030D010SQW1H 4" LED Precision High Center Beam Square Downlight, 1000 Lumens, No Optic, 90 CRI, 3000K, 120-277V, 0-10V Dim to 1%, 45 Degrees Cutoff, Self-Flanged Trim, Semi-Specular Finish
Regular price
Price:
$450.45
Regular price
Price:
Sale price
$450.45
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
Lower Shielding Reflector
ORDERING INFORMATION
Lower Shielding Reflector
- Painted die cast aluminum or 45° cutoff anodized aluminum reflector providing minimal source brightness.
- Anodized reflectors are offered in all Portfolio finishes.
- Reflector is retained with two torsion springs holding the flange tight to the finished ceiling surface.
- Plaster lathing ring, knife edge and millwork ring accessory for flush reflector transition
- Interchangeable silicone optic in 5 degrees increment from 10 degrees - 70 degrees providing smooth beam without color separation
- Elliptical beams
- Available media holder fits onto optic holder and holds up to two lens media
- Two torsion springs hold reflector flange tightly to the finished ceiling surface
- Galvanized steel plaster frame with adjustable collar adjusts for up to 2" thick ceilings and rotates+/- 7.5 degrees.
- Accepts 1/2" Electric Metallic Tube (EMT), C-channel and bar hangers
- Adjusts 5" vertically from above and below the ceiling
- Four 1/2" and two 3/4" trade size pry outs positioned to allow straight conduit runs
- Lever connectors for simple push in wiring
- Listed for (4) #12 AWG (two in, two out) 90°C conductors and feed thru branch wiring for type IC and Plug in drivers for 120/277V only. For all other cases (8) #12 AWG (four in, four out) 90°C conductors and feed thru branch wiring for 120/277V only
- Aluminum heat sink conducts heat away from the LED module for improved performance and longer life
- Contains a plurality of high brightness white LED’s combined with a high reflectance upper reflector and convex transitional lens producing even distribution without pixilation
- Auto resetting, thermally protected, LED’s are turned off when safe operating temperatures are exceeded
- Quick disconnect allows for tool-less replacement of LED engine from below ceiling
- 90 and 97 CRI
- 90 & 97CRI: L78 55,000 hours for 1000-2000 lumens, L90 55,000 for all other lumen output
- Color variation within 2-step MacAdam ellipses
- Available in 2400K, 2700K, 3000K, 3500K, 4000K and 5000K correlated color temperature (CCT)
- W2N: L70 55,000 hours
- D2W -- dim-to-warm shifts CCT from 3000K to 1850K as fixture dims mimicking halogen sources.
- W2N - Tunable white CCT range 2700K to 6500K or 2000K to 5000K, 90 CRI. Standar
- See dedicated specification sheet for more details.
- Standard 120-277V 0-10V dimming driver provides flicker free dimming from 100% to 1%
- Optional 120V leading edge/0-10V, <1% 0-10V, Fifth Light, DMX or Lutron® Ecosystem
- Driver can be serviced from above or through the aperture
- Distributed low voltage power system combines power, lighting, and controls with ease of installation.
- Optional magnetically guided snap in driver for ease of maintenance.
- EM14RSD with simplified battery replacement and self diagnostics
Connected Lighting System
Two WaveLinx connected solutions to choose from. Refer to WaveLinx system specifications and application guides for details.
WaveLinx PRO Tilemount Sensor KitTwo WaveLinx connected solutions to choose from. Refer to WaveLinx system specifications and application guides for details.
- WaveLinx PRO WPST tilemount sensor kit offers daylight dimming, PIR motion sensing, scene and zone configuration, automatic commissioning; and optional RLTS - Real Time Location Services available.
- WaveLinx PRO WPN wireless node provides luminaire-level control with scene and zone configuration without an integrated sensor; Connects wirelessly with daylight dimming sensor and PIR motion sensor if desired. Use with 0-10V driver only. Note: Not compatible with 347V or Chicago plenum.
- WaveLinx LITE WLST tilemount sensor kit offers daylight dimming and PIR motion sensing, scene and grouping configuration.
- WaveLinx LITE WLN wireless node provides luminaire level control with scene and zone configuration without an integrated sensor; Connects wirelessly with daylight dimming sensor and PIR motion sensor if desired. Use with 0-10V driver only. Note: Not compatible with 347V or Chicago plenum.
- The WPST and WLST tilemount sensor kits include a control module mounted on the luminaire junction box via 1/2" knock-out, and a tilemount sensor on 54-inch whip; for ceiling installation by direct-mount spring clips or via mounting bracket in octagon ceiling boxes.
- The WPST and WLST tilemount sensor kits may be ordered as factory installed on the luminaire, or ordered separately as a field installed accessory kit.
- Note: WaveLinx PRO devices are only compatible with the WaveLinx PRO system.
- Note: WaveLinx LITE devices are only compatible with the WaveLinx LITE system.
- Thermally protected
- cULus Certified to UL 1598 / C22.2 No. 250.0 suitable for damp locations with covered ceiling
- Optional City of Chicago environmental air (CCEA) marking for plenum applications
- FCC CFR Title 47 Part 15 Class B at 120VAC and Class A at 277VAC
- Insulated ceiling (IC) rated up to 1000 lumens for 10°, 15° and 20° beams, 1500 lumens for 25° beam and above. All others are non-IC rated (insulation must be kept 3" from top and sides of housing).
- Can be used for State of California Title 24 high efficacy LED compliance under JA8*, reference Modernized Appliance Efficiency Database System (MAEDBS) for 2016 JA8 High Efficacy Lighting\
- RoHS compliant*
- Photometric testing completed in accordance with IES LM-79
- LED life testing completed in accordance with IES LM-80-08 and TM-21-11 standards
- Five year warranty
ORDERING INFORMATION
