Prescolite LD4-S-D-120V-6L-35K-FL30-WH 4" Wall Mount Downlight Only LED Cylinder, White Finish, 600 Lumens, 80 CRI, Non Dimming, 120V
Prescolite LD4-S-D-120V-6L-35K-FL30-WH 4" Wall Mount Downlight Only LED Cylinder, White Finish, 600 Lumens, 80 CRI, Non Dimming, 120V
Regular price
Price:
$294.40
Regular price
Price:
Sale price
$294.40
Unit price
per
MODEL: Prescolite-LD4-S-D-120V-6L-op1
Usually Ships in 4-6 business days. Urgent Project? Contact Us
Couldn't load pickup availability
Ordering a large quantity?Request a quote
description
APPLICATIONS:
The LD4 is a 4" direct/indirect wall mount LED cylinder to achieve illumination patterns on vertical walls or columns. The LD4 is suitable for a wide variety of commercial, retail and institutional applications including building exterior, column, and corridor illumination. Suitable applications with ambient temperatures up to 30 degree C (86 degree F) during operation.
HOUSING:
.125" thick seamless extruded aluminum cylinder with diecast aluminum, arm, and mounting bracket. Interlocking parts insure proper cylinder alignment. Gasketed die cast lens ring is threaded to screw into cylinder for snug fit. The rings are provided with anti-rotation set screws that lock them in place. Durable powder coated paint finish. Specify: matte black, matte white, bronze, or Prescolite’s exclusive Zet, metallic silver. All components are non-corrosive.
LEDs:
Each array is equipped with (6) 1 watt, 80 CRI LEDs with integral heat sink that will provide 70% average lumen maintenance at 50,000 hours.
LED DRIVER:
Energy efficient electronic constant current, non-dimming driver with 50,000 hour minimum anticipated life. Meets UL Class 2, FCC 47CFR Class A compliant, inherent short-circuit protection, self limited, overload protected.
LABELS:
CSA C/US Suitable for wet location.
WARRANTY:
5 year warranty.
ORDERING INFORMATION:
The LD4 is a 4" direct/indirect wall mount LED cylinder to achieve illumination patterns on vertical walls or columns. The LD4 is suitable for a wide variety of commercial, retail and institutional applications including building exterior, column, and corridor illumination. Suitable applications with ambient temperatures up to 30 degree C (86 degree F) during operation.
HOUSING:
.125" thick seamless extruded aluminum cylinder with diecast aluminum, arm, and mounting bracket. Interlocking parts insure proper cylinder alignment. Gasketed die cast lens ring is threaded to screw into cylinder for snug fit. The rings are provided with anti-rotation set screws that lock them in place. Durable powder coated paint finish. Specify: matte black, matte white, bronze, or Prescolite’s exclusive Zet, metallic silver. All components are non-corrosive.
LEDs:
Each array is equipped with (6) 1 watt, 80 CRI LEDs with integral heat sink that will provide 70% average lumen maintenance at 50,000 hours.
LED DRIVER:
Energy efficient electronic constant current, non-dimming driver with 50,000 hour minimum anticipated life. Meets UL Class 2, FCC 47CFR Class A compliant, inherent short-circuit protection, self limited, overload protected.
LABELS:
CSA C/US Suitable for wet location.
WARRANTY:
5 year warranty.
ORDERING INFORMATION:
downloads
Download PDF Specification Share your knowledge of this product. Be the first to write a review »
