RAB ALED26 LED 26W Area Light, No Photocell, 5000K (Cool), 2662 Lumens, 70 CRI, Standard Operation, Bronze Finish
RAB ALED26 LED 26W Area Light, No Photocell, 5000K (Cool), 2662 Lumens, 70 CRI, Standard Operation, Bronze Finish
Regular price
Price:
$387.60
Regular price
Price:
Sale price
$387.60
Unit price
per
free shiping
details >>
Ordering a large quantity?
Request a quote
Find your items based on model numbers and product specification. Photo might not represent the actual item or color. Often times, photo is used as a representation of a product family
description
Features & Benefits
- High Output LED Light Engine
- Maintains 70% of initial lumens at 50,000 hours
- Weatherproof high temperature silicone gaskets
- Superior Heat Sinking with Die Cast Aluminum Housing and External Fins
| Model # | ALED26 |
| Lumen Maintenance | The LED will deliver 70% of its initial lumens at 50,000 hours of operation. |
| Housing | Precision die cast aluminum housing, lens frame. |
| Gaskets | High temperature silicone |
| Finish | Chip and fade resistant polyester powder coat finish. |
| Green Technology | ALEDs are Mercury, Arsenic and UV free. |
| IESNA LM-79 & IESNA LM-80 Testing | RAB LED luminaires have been tested by an independent laboratory in accordance with IESNA LM-79 and 80, and have received the Department of Energy "Lighting Facts" label. |
| Color Stability | RAB LEDs exceed industry standards for chromatic stability. |
| Color Uniformity | RAB?s range of CCT (Correlated color temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2008. |
| Ambient Temperature | Suitable for use in 40C ambient temperatures. |
| Cold Weather Starting | The minimum starting temperature is -40?C |
| LED Light Engine | Multi-chip 26W high output long life LED Driver Constant Current, 720mA, Class 2, 6 KV Surge Protection, 100V-277V, 50-60 Hz, 100-240V .4 Amps |
| Fixture Efficacy | 61 Lumens per Watt |
| Color Accuracy | 66 CRI |
| Color Temperature | 5169 K (Daylight) |
| Heatsink | Cast aluminum thermal management system for optimal heat sinking. The ALED is designed for cool operation, most efficient output and maximum LED life by minimizing LED junction temperature. |
| California Title 24 | ALED complies with California Title 24 building and electrical codes. |
| Patents | The ALED design is protected by U.S. PATENT D608,040 and patents pending in the U.S., Canada, China, Taiwan and Mexico. |
| Equivalency | The ALED26 is Equivalent in delivered lumens to a 70 W Metal Halide Area Light |
| HID Replacement Range | The ALED26 can be used to replace 42 CFL - 100W Metal Halide Area Light based on delivered lumens. |
| Country of Origin | Designed by RAB in New Jersey and assembled in the USA by IBEW Local 3 |
| Buy American Act Compliant | This product is a COTS item manufactured in the United States, and is compliant with the Buy American Act. |
| Recovery Act (ARRA) Complaint | This product complies with the 52.225-21 "Required Use of American Iron, Steel, and Manufactured Goods-- Buy American Act-- Construction Materials (October 2010) |
| Trade Agreements Act Compliant | This product is a COTS item manufactured in the United States, and is compliant with the Trade Agreements Act. |
| GSA Schedule | This product is suitable for listing on the GSA Schedule of the US General Services in accordance with FAR Subpart 25.4 |
| UL Listing | Suitable for wet locations. Suitable for mounting within 4' of the ground. |
| Warranty | RAB LED fixtures give you peace of mind because both the fixture and light engine components are backed by RAB's 5 Year Warranty. |
Download PDF specification Share your knowledge of this product. Be the first to write a review »
