RAB BRISK17FA20W 20W 3000/4000/5000K Field-Adjustable LED Wallpack

Color temperature selectable by 3000K, 4000K and 5000K

Suitable for wet locations

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Ingress protection rating of IP65 for dust and water

This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Equivalent to 100W Metal Halide

Long-life, high-efficiency, surface-mount LEDs

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Constant Current, Class 2, 120-277V, 50/60 Hz, 120V: 0.20A, 208V: 0.10A, 240V: 0.08A, 277V: 0.07A

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

120-277V Discreet, integrated button photocell included. Photocell is compatible with 120V-277V.

The minimum starting temperature is -40°C (-40°F)

Suitable for use in up to 45°C (113°F)

Precision die-cast aluminum

Formulated for high durability and long-lasting color

Mercury and UV free. RoHS-compliant components.

Heavy duty, die-cast junction box with four (4) conduit entries (one top, two side, one back)

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
