RAB EZP2X2/E Field Adjustable 2' x 2' LED panel 3500/4000/5000K Color Temperature, 3409-5272 Lumens with Emergency Battery Backup
RAB EZP2X2/E Field Adjustable 2' x 2' LED panel 3500/4000/5000K Color Temperature, 3409-5272 Lumens with Emergency Battery Backup
Regular price
Price:
$227.00
Regular price
Price:
Sale price
$227.00
Unit price
per
Ordering a Large Quantity?
Request a quote
description
|
Field Adjustability
|
|
|
Field Adjustable
|
Field Adjustable Light
Output:
|
| 40W/30W/25W (factory default: 40W) | |
| Color Temperature Selectable: | |
| 3500K, 4000K and 5000K (factory default:4000K) | |
|
Compliance
|
|
|
UL Listed
|
Suitable for damp
locations
|
|
IESNA LM-79 & LM-80
Testing
|
RAB LED luminaires have
been tested by an independent laboratory in accordance with IESNAlm-79
andlm-80
|
|
Trade Agreements Act
Compliant
|
This product is a product
of Cambodia and a "designated country" end product that complies
with the Trade Agreements Act
|
|
DLC Listed
|
This product is on the
Design Lights Consortium (DLC) Qualified Products List and is eligible for
rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
|
| DLC Product Code: S-70LNZS | |
|
Electrical
|
|
|
Driver
|
Constant Current, Class
II, 120-277V, 50/60 Hz:
|
| 40W: 120V: 0.33A, 208V: 0.19A, 240V: 0.17A, 277V: 0.14A | |
| 30W: 120V: 0.25A, 208V: 0.14A, 240V: 0.13A, 277V: 0.11A | |
| 25W: 120V: 0.21A, 208V: 0.12A 240V: 0.10A, 277V: 0.09A | |
|
Dimming Driver
|
Driver includes dimming
control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming
circuit. Dims down to 10%.
|
|
Power Factor
|
99.3% at 120V, 97.4% at
277V
|
|
Aux Power Supply
|
No
|
|
Dim to Off
|
Yes
|
|
Battery Backup
|
Battery backup will
operate the LED Lamp for 90 minutes if power fails. Wired for 120V-277V.
|
|
Battery Backup Light Loss
Factor
|
40W: 37.5%
|
| 30W: 50% | |
| 25W: 60% | |
|
Surge Protection
|
2kV + 4kV
|
|
Construction
|
|
|
Cold Weather Starting
|
The minimum starting
temperature is 0°C (32°F)
|
|
Maximum Ambient
Temperature w/Battery Backup
|
Suitable for use in up to
40°C (104°F)
|
|
IC Rated
|
Suitable for direct
contact with insulation
|
|
Lens
|
Precision engineered
polystyrene diffuser provides high uniformity, and reduced glare. No visible
diodes, hot-spots, or shadows.
|
|
Housing
|
Aluminum+Iron
|
|
Reflector
|
TPET reflective paper
|
|
Finish
|
Formulated for high
durability and long-lasting color
|
|
Green Technology
|
Mercury and UV free.
RoHS-compliant components.
|
|
Installation
|
|
|
Mounting
|
Surface, suspended &
recessed mounting. The mounting accessories sold separately.
|
|
Installation
|
Standard integral T-bar
clips secure the fixture to T-bars and prevent T-system separation
|
|
LED Characteristics
|
|
|
LEDs
|
Long-life, high-efficacy,
surface-mount LEDs
|
|
Color Stability
|
LED color temperature is
warrantied to shift no more than 200K in color temperature over a 5-year
period
|
|
Color Uniformity
|
RAB's range of Correlated
Color Temperature follows the guidelines of the American National Standard
for Specifications for the Chromaticity of Solid State Lighting (SSL)
Products, ANSI C78.377-2017.
|
|
Performance
|
|
|
Lifespan
|
100,000-Hour LED lifespan
based on IES LM-80 results and TM-21 calculations
|
|
THD
|
11.70% at 120V, 15.07% at
277V
|
|
Other
|
|
|
5-Year, No-Compromise
Warranty
|
RAB warrants that our LED
products will be free from defects in materials and workmanship for a period
of five (5) years from the date of delivery to the end user, including
coverage of light output, color stability, driver performance and fixture
finish. RAB's warranty is subject to all terms and conditions found
at rablighting.com/warranty.
|
