RAB HAZFFLED60 LED Floodlight Class 1, Division 2 Classification 60W, 5000K, 9540 Lumens
RAB HAZFFLED60 LED Floodlight Class 1, Division 2 Classification 60W, 5000K, 9540 Lumens
Regular price
Price:
$854.00
Regular price
Price:
Sale price
$854.00
Unit price
per
MODEL: RAB-HAZFFLED60
Usually Ships in 3-5 business days. Urgent Project? Contact Us
Couldn't load pickup availability
Ordering a large quantity?Request a quote
description
| Hazardous Location Classifications | |
|
Class I
|
Class I: A hazardous
location in which flammable gases or vapors may be present in the air in
sufficient quantities to be explosive or ignitable, such as petroleum
refineries, aircraft hangars, dry cleaning plants, utility gas plants or
storage areas for liquified petroleum or natural gas, and spray finishing
areas.
|
|
Division 2
|
Division 2: Abnormal
condition, where ignitable concentrations of flammable gases, vapors or
liquids are not like to exist under normal operating conditions, for example:
|
|
Division 2
|
Closed storage drums containing flammable liquids in an inside storage room would not normal allow the hazardous vapors to escape into the atmosphere. But if one of the containers is leaking, you've got an abnormal condition. |
|
Groups A - D
|
Groups A - D: The gases
and vapors of Class 1 locations are broken into four groups by the Code:
A,B,C, and D. These materials are grouped according to the ignition
temperature of the substance, its explosion pressure, and other flammable
characteristics.
|
|
Groups A - D
|
Group A - The only substance in group A is acetylene because it is a gas with extremely high explosion pressures. |
|
Groups A - D
|
Group B - This group includes hydrogen and other materials with similar characteristics. |
|
Groups A - D
|
Group C & D - The most usual Class 1 groups. They comprise the greatest percentage of all Class I hazardous locations. Found in Group C is ethylene. Found in Group D are many of the most common flammable substances such as butane, gasoline, natural gas and propane. |
|
NEC/CE T-Code
|
T4A
|
|
UL 844
|
Electric lighting
fixtures for use in hazardous (classified) locations
|
|
Compliance
|
|
|
UL Listed
|
Suitable for wet
locations. Suitable for mounting within 4 ft (1.2m) of the ground.
|
|
IP Rating
|
Ingress protection rating
of IP66 for dust and water
|
|
DLC Listed
|
This product is on the
Design Lights Consortium (DLC) Qualified Products List and is eligible for
rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.
|
|
DLC Listed
|
DLC Product Code: S-KNUFEM |
|
Electrical
|
|
|
Driver
|
Constant Current, Class
1, 120-277V, 50/60 Hz, 120V: 0.51A, 208V: 0.32A, 240V: 0.28A, 277V: 0.24A
|
|
Dimming Driver
|
Driver includes dimming
control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming
circuit. Dims down to 10%.
|
|
THD
|
2.77% at 120V, 7.86% at
277V
|
|
Power Factor
|
99.7% at 120V, 91.2% at
277V
|
|
Surge Protection
|
L/N-G 10KV, L-N 6KV
|
|
Optical
|
|
|
NEMA Type
|
7H x 6V Beam Spread
|
|
Construction
|
|
|
Cold Weather Starting
|
The minimum starting
temperature is -40°C (-40°F)
|
|
Maximum Ambient
Temperature
|
Suitable for use in up to
55°C (131°F)
|
|
Housing
|
Die-cast aluminum
|
|
Reflector
|
High-reflective
polycarbonate
|
|
Mounting
|
Yoke
|
|
Lens
|
Clear glass lens
|
|
Tilt Increment
|
Rotates in 6 degree
increments
|
|
Effective Projected Area
|
EPA = 0.67
|
|
Gaskets
|
High-temperature silicone
|
|
Green Technology
|
Mercury and UV free.
RoHS-compliant components.
|
|
Finish
|
Formulated for high
durability and long-lasting color
|
|
LED
Characteristics
|
|
|
LEDs
|
Long-life, high-efficacy,
surface-mount LEDs
|
|
Color Uniformity
|
RAB's range of Correlated
Color Temperature follows the guidelines of the American National Standard
for Specifications for the Chromaticity of Solid State Lighting (SSL)
Products, ANSI C78.377-2017.
|
|
Color Consistency
|
7-step MacAdam Ellipse
binning to achieve consistent fixture-to-fixture color
|
|
Other
|
|
|
5 Yr Limited Warranty
|
5 Yr Limited Warranty
|
|
Buy American Act
Compliance
|
RAB values USA
manufacturing! Upon request, RAB may be able to manufacture this product to
be compliant with the Buy American Act (BAA). Please contact customer service
to request a quote for the product to be made BAA compliant.
|
|
Performance
|
|
|
Wattage Equivalency
|
Equivalent to 250W Metal
Halide (MH) or 200W High Pressure Sodium (HPS)
|
