RAB HAZLED60WMCG 60W Hazardous Location LED Light, 8215 Lumens, 5000K, 80 CRI, Wall Mount
RAB HAZLED60WMCG 60W Hazardous Location LED Light, 8215 Lumens, 5000K, 80 CRI, Wall Mount
Regular price
Price:
$724.91
Regular price
Price:
Sale price
$724.91
Unit price
per
Ordering a Large Quantity?
Request a quote
description
| Hazardous Location Classifications | |
|
Class I Division 2
(Groups A, B, C, D)
|
Class I: A hazardous
location in which flammable gases or vapors may be present in the air in
sufficient quantities to be explosive or ignitable, such as petroleum
refineries, aircraft hangars, dry cleaning plants, utility gas plants or
storage areas for liquified petroleum or natural gas, and spray finishing
areas.
|
| Division 2: Abnormal condition, where ignitable concentrations of flammable gases, vapors or liquids are not like to exist under normal operating conditions, for example:Closed storage drums containing flammable liquids in an inside storage room would not normal allow the hazardous vapors to escape into the atmosphere. But if one of the containers is leaking, you've got an abnormal condition. | |
| Group A - The only substance in group A is acetylene because it is a gas with extremely high explosion pressures. | |
| Group B - This group includes hydrogen and other materials with similar characteristics. | |
| Group C & D - The most usual Class 1 groups. They comprise the greatest percentage of all Class I hazardous locations. Found in Group C is ethylene. Found in Group D are many of the most common flammable substances such as butane, gasoline, natural gas and propane. | |
|
Class II Division 1
(Groups E, F, G)
|
Class II: Combustible
dust may be present
|
| Division 1: Ignitable concentrations of hazards exist under normal operation conditions and/or where the hazard is caused by frequent maintenance or repair work or frequent equipment failure | |
| E: Combustible metal dusts: aluminum, commercial alloys and magnesium | |
| F: Combustible carbonaceous dusts: carbon black, charcoal, coal and coke dusts | |
| G: Other combustible dusts: Chemicals, flour, grain, plastic and wood | |
|
Class II: Combustible
dust may be present
|
|
| Division 2: Ignitable concentrations of hazards exist under abnormal operation conditions | |
| F: Combustible carbonaceous dusts: carbon black, charcoal, coal and coke dusts | |
| G: Other combustible dusts: Chemicals, flour, grain, plastic and wood | |
|
Class III
|
Class III: Easily
ignitable fibers or flyings may be present
|
|
UL 844
|
Electric lighting
fixtures for use in hazardous (classified) locations
|
|
UL 1598
|
Electric lighting
fixtures for use in non-hazardous locations
|
|
Compliance
|
|
|
UL Listed
|
Suitable for wet
locations
|
|
IESNA LM-79 & LM-80
Testing
|
RAB LED luminaires and
LED components have been tested by an independent laboratory in accordance
with IESNA LM-79 and LM-80.
|
|
IP Rating
|
Ingress protection rating
of IP66 for dust and water
|
|
DLC Listed
|
This product family is
listed with the DesignLights Consortium (DLC). Individual SKUs within this
family may carry either a DLC Standard or DLC Premium qualification. Please
refer to the individual product specification sheet or the DLC Qualified
Products List (QPL) at designlights.org to confirm the
qualification status of a specific SKU prior to specification or purchase.
|
|
Electrical
|
|
|
Driver
|
Constant Current, Class
2, 50/60 Hz, 120V-277V, 120V: 0.48A, 208V: 0.29A, 240V: 0.25A, 277V: 0.22A
|
|
Dimming Driver
|
Driver includes dimming
control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming
circuit. Dims down to 10%.
|
|
THD
|
3.87% at 120V, 6.51% at
277V
|
|
Power Factor
|
99.8% at 120V, 91.9% at
277V
|
|
Surge Protection
|
L-N:4 kV
|
| L/N-FG:6 kV | |
|
Construction
|
|
|
Cold Weather Starting
|
The minimum starting
temperature is Ta = -40°C (-40°F)
|
|
Maximum Ambient
Temperature
|
|
|
Housing
|
Die-cast aluminum
|
|
Lens/Globes
|
Clear globes
|
|
Gaskets
|
High-temperature silicone
|
|
Green Technology
|
Mercury and UV free.
RoHS-compliant components.
|
|
Finish
|
Formulated for high
durability and long-lasting color
|
|
Installation
|
|
|
Mounting
|
Wall mount
|
|
LED
Characteristics
|
|
|
LEDs
|
Long-life, high-efficacy,
surface-mount LEDs
|
|
Color Uniformity
|
RAB's range of Correlated
Color Temperature follows the guidelines of the American National Standard
for Specifications for the Chromaticity of Solid State Lighting (SSL)
Products, ANSI C78.377-2017.
|
|
Color Consistency
|
7-step MacAdam Ellipse
binning to achieve consistent fixture-to-fixture color
|
|
Performance
|
|
|
Lifespan
|
100,000-Hour LED lifespan
based on IESlm-80 results and TM-21 calculations
|
|
Optical
|
|
|
BUG Rating
|
B3 U0 G1
|
|
Other
|
|
|
5-Year, No-Compromise
Warranty
|
RAB warrants that our LED
products will be free from defects in materials and workmanship for a period
of five (5) years from the date of delivery to the end user, including
coverage of light output, color stability, driver performance and fixture
finish. RAB's warranty is subject to all terms and conditions found
at rablighting.com/warranty.
|
Download PDF SpecificationShare your knowledge of this product. Be the first to write a review »
