RAB HAZVX30 30W Hazardous Location Vaporproof Light, 5000K, 3869 Lumens, Surface Mount
RAB HAZVX30 30W Hazardous Location Vaporproof Light, 5000K, 3869 Lumens, Surface Mount
Regular price
Price:
$447.30
Regular price
Price:
Sale price
$447.30
Unit price
per
Ordering a Large Quantity?
Request a quote
description
| Hazardous Location Classifications | |
|
UL 844
|
Electric lighting
fixtures for use in hazardous (classified) locations
|
|
Class 1, Division 2
(Groups A, B, C, D)
|
Class 1 (Hazardous
Material in Surrounding Atmosphere):
|
| Flammable vapors or gases may be present | |
| Division 2 (Presence of Hazardous Materials): | |
| Ignitable concentrations of hazards exist only under accidental system breakdowns or abnormal operating conditions | |
| Groups A, B, C, D (Hazardous Material in Surrounding Atmosphere): | |
| A = Acetylene | |
| B = Hydrogen, butadiene, ethylene oxide, propylene oxide and acrolein | |
| C = Ethylene, cyclopropane and ethyl ether | |
| D = Acetone, ammonia, benzene, butane, ethanol, gasoline, hexane, methane, methanol, naphta, natural gas, propane & toluene | |
|
UL 1598
|
Electric lighting
fixtures for use in non-hazardous locations
|
|
UL 1598A
|
UL 1598A includes
requirements for materials that can withstand exposure to saltwater,
humidity, and other corrosive elements.
|
|
UL 8750
|
Light Emitting Diode
(LED) Light Sources for Use in Lighting Products
|
|
Construction
|
|
|
IK Rating
|
IK08 Protected against 5
joules of impact. Equivalent to the impact of a 3.75 lbs. (1.7kg) mass
dropped from 11.8" (300mm) above the impacted surface.
|
|
Cold Weather Starting
|
The minimum starting
temperature is -40°F (-40°C)
|
|
Maximum Ambient
Temperature
|
Suitable for use in up to
122°F (50°C)
|
|
Housing
|
Aluminum
|
|
Lens
|
Glass
|
|
Gaskets
|
High-temperature silicone
|
|
Green Technology
|
Mercury and UV free.
RoHS-compliant components.
|
|
Finish
|
Formulated for high
durability and long-lasting color
|
|
Compliance
|
|
|
UL Listed
|
Suitable for wet
locations
|
|
IESNA LM-79 & LM-80
Testing
|
RAB LED luminaires and
LED components have been tested by an independent laboratory in accordance
with IESNA LM-79 and LM-80.
|
|
IP Rating
|
Ingress protection rating
of IP66 for dust and water
|
|
Electrical
|
|
|
Driver
|
Constant Current, Class
1, 120-277V, 50/60 Hz, 120V: 0.30A, 208V: 0.18A, 240V: 0.16A, 277V: 0.15A
|
|
Dimming Driver
|
Driver includes dimming
control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming
circuit. Dims down to 10%.
|
|
THD
|
2.89% at 120V, 7.52% at
277V
|
|
Power Factor
|
99.4% at 120V, 90.1% at
277V
|
|
Surge Protection
|
L-N:1 kV
|
|
Aux Power Supply
|
No
|
|
Dim to Off
|
Yes
|
|
Installation
|
|
|
Mounting
|
Ceiling mount with
rotating cap
|
|
LED
Characteristics
|
|
|
LEDs
|
Long-life, high-efficacy,
surface-mount LEDs
|
|
Color Uniformity
|
RAB's range of Correlated
Color Temperature follows the guidelines of the American National Standard
for Specifications for the Chromaticity of Solid State Lighting (SSL)
Products, ANSI C78.377-2017.
|
|
Color Consistency
|
7-step MacAdam Ellipse
binning to achieve consistent fixture-to-fixture color
|
|
Performance
|
|
|
Lifespan
|
100,000-Hour LED lifespan
based on IES LM-80 results and TM-21 calculations
|
|
Other
|
|
|
5-Year, No-Compromise
Warranty
|
RAB warrants that our LED
products will be free from defects in materials and workmanship for a period
of five (5) years from the date of delivery to the end user, including
coverage of light output, color stability, driver performance and fixture
finish. RAB's warranty is subject to all terms and conditions found
at rablighting.com/warranty.
|
