RAB KAI-4T100RG/7PRS 100/80/60W LED Roadway Light, Adjustable CCT 3000K/4000K/5000K, 9039-14817 Lumens, 82-84 CRI

Field Adjustable Light Output:

Suitable for wet locations

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Ingress protection rating of IP66 for dust and water

This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities.

Constant Current, Class1, 120-277V, 50/60 Hz:

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

10 kV

Yes

Yes

ANSI C136.41 7-pin receptacle, compatible with wireless control systems

The Type IV distribution (also known as a Forward Throw) is especially suited for mounting on the sides of buildings and walls, and for illuminating the perimeter of parking areas. It produces a semicircular distribution with essentially the same candlepower at lateral angles from 90° to 270°.

100W: B3-U0-G3

Long-life, high-efficacy, surface-mount LEDs

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

100,000-Hour LED lifespan based on IESlm-80 results and TM-21 calculations

IK08 Protected against 5 joules of impact. Equivalent to the impact of a 3.75 lbs. (1.7kg) mass dropped from 11.8" (300mm) above the impacted surface.

The minimum starting temperature is -40°F (-40°C)

Suitable for use in up to 104°F (40°C)

Die-cast aluminum

Rotates in 2.5 degree increments

EPA = 0.37

Clear polycarbonate lens

3G vibration rating per ANSI C136.31

High-temperature silicone

Formulated for high durability and long-lasting color

Mercury and UV free. RoHS-compliant components.

Adjustable universal pole mount
