RAB PRT55N/WS 55W LED PORTO Garage Light, No Photocell, 4000K (Neutral), 120-277V, Multi-Level Motion Sensor for 14", Standard, Bronze Finish

Suitable for wet locations

Ingress protection rating of IP66 for dust and water

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.

Constant Current, Class 2 100V - 277V, 50/60 Hz. THD <20%.

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

7.9% at 120V, 6.8% at 277V

99.2% at 120V, 97.1% at 277V

Frosted polycarbonate

High-temperature silicone

Suitable for use in up to 40°C (104°F)

Formulated for high durability and long-lasting color

The minimum starting temperature is -40°C (-40°F)

Superior thermal management with external "Air-Flow" fins

Die-cast aluminum and sheetmetal housing. Polycarbonate is affected by cleaning agents or other liquids containing partial solvents such as low molecular weight aldehydes and ethers, ketones, esters, aromatic hydrocarbons and perchlorinated hydrocarbons. Click here for a detailed list of damaging chemicals.

Die-cast aluminum backbox with (4) 1/2" conduit openings with plugs. Hinged tether for easy installation and wiring. Also accommodates 1/2" or 3/4" NPS pendants (provided by others).

Specular polycarbonate

Mercury and UV free. RoHS-compliant components.

Long-life, high-efficacy, surface-mount LEDs

7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

Equivalent to 150W Metal Halide

RAB warrants that our LED products will be free from defects in materials and workmanship for a period of five (5) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.

RAB values USA manufacturing! Upon request, RAB may be able to manufacture this product to be compliant with the Buy American Act (BAA). Please contact customer service to request a quote for the product to be made BAA compliant.

120-277V

1W

50mA

High: 0-10V; Low: off, 0-9.8V

Amount of time in high mode with no motion before switching to low mode: 5 min., 1 -30 min.

Time in which the fixture will remain on low mode with no motion before turning off and waiting for new motion to turn on: None, 1 -60 min., 1 -5 hrs.

None, low, medium, maximum

None, 1 to 250 fc, auto

-40°F to 167°F (-40°C to +75°C)

20% to 90% noncondensing

200,000 cycles (120/277VAC), 50,000 cycles (230VAC)

Ingress protection rating of IP66 for dust and water

Suitable for Wet Locations as factory installed

Adjust settings using handheld wireless configuration tool (catalog# WSREM). Only available with 0-10V dimming driver options. Handheld wireless configuration tool available here.
