RAB RWLED2T105YRG 105W LED Universal Adaptor Lamp, 3000K (Warm), Type II Light Distribution, Standard Operation, 120-277V, No Photocell, Gray Finish

Description

LED roadway lighting that's easy to buy. Free trial program and leasing options make it easy to get started with LED. Specification-grade optics deliver efficient, clean, uniform light distributions at a reasonable cost. Optics are factory installed and meet IES Lateral Distribution Type II. LROAD™ 105W replaces 320W metal halide roadway fixtures.

Features and Benefits

• Ideal for entrance roadways, collector roads, and single-sided roads
• 27 year lifespan dramatically reduces maintenance and re-lamping costs
• Precision optics deliver maximum downward street side lumens with uniformity and minimal glare
• Compatible with standard roadway arms
• Universal adaptors for 1", 1 1/4", 1 1/2" and 2" OD pipe included
• Industry-leading 5G vibration rating per ANSI C136.31
• Easy-access electrical compartment makes wiring fast and secure
• 10-Year no compromise warranty

• UL Listing:
  Suitable for wet locations as a downlight.
• DLC Listed:
  This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.
• IESNA LM-79 & IESNA LM-80 Testing:
  RAB LED fixtures have been tested by an independent laboratory in accordance with IESNA LM-79 and 80, and have received the Department of Energy "Lighting Facts" label.
• Dark Sky Approved:
  The International Dark Sky Association has approved this product as a full cutoff, fully shielded luminaire.

• Lumen Maintenance:
  100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations.

• IES Classification:
  The Type II distribution is ideal for entrance roadways, collector roads and other long, single-sided and narrow lighting applications. This type of lighting is commonly found on smaller local streets.
• Effective Projected Area:
  EPA = 0.75
• IP Rating:
  Ingress Protection rating of IP66 for dust and water.
• Vibration Rating:
  Industry-leading 5G vibration rating per ANSI C136.31.
• Ambient Temperature:
  Suitable for use in 40°C ambient temperatures.
• Cold Weather Starting:
  The minimum starting temperature is -40°F/-40°C.
• Thermal Management:
  Superior patent pending thermal management design with external Air-Flow fins provides maximum operational life, even in high ambient temperature environments.
• Housing:
  Die cast aluminum housing, lens frame and mounting arm.
• Mounting:
  Fits most standard roadway upsweep arms. Adaptor brackets supplied fit 1", 1 1/4", 1 1/2" and 2" OD arms.
• Wedge Mounting Option:
  Allows field adjustment of +/- 5 degree tilt to achieve a level installation of LROAD105 universal adaptor roadway fixtures.Wedge Mounting sold separately.
• Recommended Mounting Height:
  Up to 25 ft.
• Reflector:
  Specular vacuum-metallized polycarbonate
• Gaskets:
  High temperature silicone gaskets
• Finish:
  Our environmentally friendly polyester powder coatings are formulated for high-durability and long-lasting color, and contains no VOC or toxic heavy metals.
• Green Technology:
  Mercury and UV free, and RoHS compliant. Polyester powder coat finish formulated without the use of VOC or toxic heavy metals.

• LEDs:
  Multi-chip, high-output, long-life LEDs
• Color Consistency:
  7-step MacAdam Ellipse binning to achieve consistent fixture-to-fixture color.
• Color Stability:
  LED color temperature is warrantied to shift no more than 200K in CCT over a 5 year period.
• Color Uniformity:
  RAB's range of CCT (Correlated Color Temperature) follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2011.

• Drivers:
  Two Drivers Constant Current, Class2, 1400mA, 100-277V, 50/60Hz, 0.8A, Power Factor 99%
• THD:
  7.6% at 120V, 16.4% at 277V
• Surge Protection:
  6kV surge suppression protection tested in accordance with IEEE/ANSI C62.41.2.

• Equivalency:
  LROAD™ 105W replaces 320W metal halide
• California Title 24:
  See RWLED2T105/BL, RWLED2T105/PCS, RWLED2T105/PCS2, or RWLED2T105/PCT for a 2013 California Title 24 compliant product. Any additional component requirements will be listed in the Title 24 section under technical specifications on the product page.
• Patents:
  The LROAD™ design is protected by patents pending in the U.S., Canada, China, Taiwan and Mexico.
• Warranty:
  RAB warrants that our LED products will be free from defects in materials and workmanship for a period of ten (10) years from the date of delivery to the end user, including coverage of light output, color stability, driver performance and fixture finish.
• Country of Origin:
  Designed by RAB in New Jersey and assembled in the USA by RAB's IBEW Local 3 workers.
• Buy American Act Compliant:
  This product is a COTS item manufactured in the United States, and is compliant with the Buy American Act.
• Recovery Act (ARRA) Compliant:
  This product complies with the 52.225-21 "Required Use of American Iron, Steel, and Manufactured Goods-- Buy American Act-- Construction Materials (October 2010).
• Trade Agreements Act Compliant:
  This product is a COTS item manufactured in the United States, and is compliant with the Trade Agreements Act.
• GSA Schedule:
  Suitable in accordance with FAR Subpart 25.4.
