RAB STL200W/240 Stealth Sensorwith 200 Degree View, 240 Volts, White
RAB STL200W/240 Stealth Sensorwith 200 Degree View, 240 Volts, White
Regular price
Price:
$155.72
Regular price
Price:
Sale price
$155.72
Unit price
per
Ordering a large quantity?
Request a quote
Find your items based on model numbers and product specification. Photo might not represent the actual item or color. Often times, photo is used as a representation of a product family
description
Description
STEALTH Sensor with special 200 degrees detection pattern to provide wide coverage side to side. Excellent for building perimeter protection. Blinders allow customization of detection zone.
Features & Benefits
- Temperature Compensation
- Easy to read controls
- Radio frequency immunity
- 6000 volt surge protection
- Quick test time
- LED Detection & "On Guard" Indicator
- Color matched vandal resistant lens and grill
- Protected manual override with auto reset
- Can be wired in parallel
- Comprehensive manuals
- 10 year warranty
| UL Listing: | Suitable for wet locations |
| Power Consumption: | 1 watt |
| Time Adjustment: | 5 seconds to 12 minutes |
| Surge Protection: | Withstands up to 6000 volts |
| Wide Sensitivity Control: | Adjustable from 100% to 30% |
| Temperature Compensation: | Sensitivity adjusted automatically for consistent detection in hot and cold ambient temperatures. |
| Wall Switch Manual Override: | Two flip logic prevents activation by momentary power outages. Override resets to auto at dawn. No extra wiring needed. |
| LED Detection Indicator: | Shows when sensor is detecting in daytime and glows red at night for "on-guard" deterrence |
| Advanced Detection Logic: | Minimizes false triggers |
| Color Matched Lens: | Dark lens with bronze units, white lens with white units |
| RF Immunity: | Circuits fully shielded for maximum radio frequency immunity. |
| Horizontal Lock, No-tool Joints: | Keeps sensing pattern level for fast, error-free installation. |
| Photoelectric Control: | Deactivates lights during daylight. Fully adjustable for 24 hour operation or custom applications |
| Floodlights: | Precision die cast aluminum. 1/2" NPS threaded arm with serrated locking swivel fits all standard mounting boxes and covers |
| Voltage: | 240 Volts, 50 Hertz |
| Detection: | 200 degrees views |
| Switching Capacity: | 1000 watts incandescent @ 120 volts, 8 amps |
| Patents: | RAB sensor and fixture designs are protected under U.S. and International Intellectual Property laws. |
Download PDF Specification (English)Share your knowledge of this product. Be the first to write a review »
