RAB TRLED2X4-50Y/D10 50W 2' x 4' LED Troffer, 3000K Color Temperature(Warm), Dimmable, White Finish

Description

LED performance in an economical 2x4 troffer.

Features and Benefits

• High efficiency, low maintenance alternative to fluorescent
• Prismatic lens with diffusion for enhanced optical performance
• 0-10V dimming standard on all models
• Optional recessed mounting kit available
• 100,000-hour LED lifespan
• 5-Year warranty

• UL Listing:
  Suitable for damp locations
• IESNA LM-79 & LM-80 Testing:
  RAB LED luminaires have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80, and have received the Department of Energy "Lighting Facts" label.
• DLC Listed:
  This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities.

• Driver:
  Constant Current, Class 2, 4-channel driver with 0-10V dimming, 350mA, 120-277VAC 0.46A, Power Factor >94%
• THD:
  10.4% at 120V, 12.5% at 277V

• Lens:
  Nominal .125" thick prismatic acrylic lens with diffusion for enhanced optical performance
• IC Rating:
  Suitable for insulated ceilings
• Housing:
  Die-formed 22 gauge, cold-rolled steel
• Installation:
  Standard integral earthquake and NEC T-bar clips secure the fixture to T-bars and prevent T-system separation. For recessed mounting kit see click here.
• Finish:
  High-reflectance (91%) powder coat applied post production for a more durable finish
• Green Technology:
  Mercury and UV free, and RoHS compliant. Polyester powder coat finish formulated without the use of VOC or toxic heavy metals.

• LEDs:
  Long-life, high-efficiency, micro-power, surface mount LEDs; binned and mixed for uniform light output and color.
• Lifespan:
  100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations.
• Color Stability:
  LED Color temperature is warrantied to shift no more than 200K in CCT over a 5 year period.

• TRLED2X4-50 with Dimmable Driver:
  Driver includes dimming control for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims as low as 5%.
• California Title 24:
  TRLED2X4-50Y/D10 complies with 2013 California Title 24 building and electrical codes as a commercial indoor fixture for general spaces when used with a vacancy sensor and 0-10V dimming control. Select a vacancy sensor using catalog number LVS800. 0-10V dimmer provided by others.
• Country of Origin:
  Designed by RAB in New Jersey and assembled in the USA by RAB's IBEW Local 3 workers.
• Buy American Act Compliant:
  This product is a COTS item manufactured in the United States, and is compliant with the Buy American Act.
• Recovery Act (ARRA) Compliant:
  This product complies with the 52.225-21 "Required Use of American Iron, Steel, and Manufactured Goods-- Buy American Act-- Construction Materials (October 2010).
• Trade Agreements Act Compliant:
  This product is a COTS item manufactured in the United States, and is compliant with the Trade Agreements Act.
• GSA Schedule:
  Suitable in accordance with FAR Subpart 25.4.
