RAB WFRX-2 10/8/6W 2" Field Adjustable LED Downlight, Selectable CCT 2700/3000/3500/4000/5000K, 900/700/520 Lumens, 120V, White

2" Edge-Lit Slim Canless Downlight

2" wafers with selectable wattage and CCT that boast 90 CRI. Designed for 120V use and TRIAC dimming, these wafers are available with a smooth lens.

60W Incandescent

10/8/6W

900/700/520lm

900/700/520lm

90/88/87lm/W

50,000-Hour LED lifespan based on IESlm-70 results

Constant Current, Class 2; 120V; 60 Hz; 120V: 100mA

≤20%

≥0.9

Yes, dimmable down to 10% on compatible 120V TRIAC/ELV dimming systems. See Dimmer Compatibility List.

120V

60Hz

100mA

≤30%

-4°F - 104°F (-20°C - 40°C)

2"

Round

White

Plastic

Metal

Smooth

Frosted

Polycarbonate light diffuser distributes light evenly and smoothly for general lighting applications

Housing certified Air Tight as per ASTM-E283

110°±10°

Field adjustable via dip switch 2700/3000/3500/4000/5000K

90 CRI

High color performance with R9 greater than 50

<4-step (2700K & 5000K) MacAdam Ellipse binning to achieve consistent fixture-to-fixture color

LED color temperature is warrantied to shift no more than 200K in color temperature over a 5-year period

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

Die formed metal driver / junction box with captive hinged junction box cover. Listed for Maximum of (4) 12AWG through branch circuit conductor suitable for 90°C permitted in box. Easy to wire in 2in/2out (plus ground) applications. (4) conduit pry-outs. (3) quick snap-in connectors for quick and reliable line voltage connections. Integral mounting facilitates direct mounting to building structure or mounting frame.

Recessed, no housing required

UL Listed

Suitable for use indoors and outdoors in dry, damp, or wet environments.

Suitable for direct contact with insulation. Type IC inherently protected, suitable for direct contact to air permeable insulation and cULus listed for damp locations. Not for use in direct contact with spray foam insulation, consult NEMA LSD57-2013.

This product is ENERGY STAR® Certified.

4016361

No

DLW0140(WFRX-2)

No

Can be used to conform with the requirements of California Title 24 Part 6

Lawful for Sales in California

Suitable for use in closets. Compliant with NEC Sec. 410.16 (A)(1) and 410.16 (C3).

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNAlm-79 andlm-80.

Mercury and UV free. RoHS-compliant components.

Complies with Part 15 of the FCC Rules

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

DLPLATE/WFR3456
