RAB X34-16L/120 15W LED Floodlight, 1735 Lumens, Knuckle Mount, 120V, 5000K Color Temperature, 80 CRI, Bronze
RAB X34-16L/120 15W LED Floodlight, 1735 Lumens, Knuckle Mount, 120V, 5000K Color Temperature, 80 CRI, Bronze
Regular price
Price:
$52.02
Regular price
Price:
Sale price
$52.02
Unit price
per
Ordering a large quantity?
Request a quote
description
PRODUCT SPECIFICATIONS
Compliance
Electrical
Driver:
Constant Current, 120V, 60 Hz, 120V: 0.13A
THD:
9.29% at 120V
Power Factor:
99.5% at 120V
Stepped Dimming:
Integrated/embedded revise Phase-Cut stepped luminance-level dimming control. Ten discrete dimming steps plus off and full on are accomplished by modification of the voltage, current, and wave form to produce varying light output. Controller is remote located from fixture or junction box, or can be located by the electrical panel.
Surge Protection:
2kV
Note:
All values are typical (tolerance +/- 10%)
Optical
NEMA Type:
NEMA Beam Spread of 7H x 7V
LED Characteristics
LEDs:
Long-life, high-efficacy, surface-mount LEDs
Color Uniformity:
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Performance
Lifespan:
50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Compliance
UL Listed:
Suitable for wet locations. Suitable for ground mounting.
IESNA LM-79 & LM-80 Testing:
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed:
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC ZZZCKU requirements. DLC Product Code: PBFBXX1P
Suitable for wet locations. Suitable for ground mounting.
IESNA LM-79 & LM-80 Testing:
RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.
DLC Listed:
This product is on the Design Lights Consortium (DLC) Qualified Products List and is eligible for rebates from DLC Member Utilities. Designed to meet DLC ZZZCKU requirements. DLC Product Code: PBFBXX1P
Electrical
Driver:
Constant Current, 120V, 60 Hz, 120V: 0.13A
THD:
9.29% at 120V
Power Factor:
99.5% at 120V
Stepped Dimming:
Integrated/embedded revise Phase-Cut stepped luminance-level dimming control. Ten discrete dimming steps plus off and full on are accomplished by modification of the voltage, current, and wave form to produce varying light output. Controller is remote located from fixture or junction box, or can be located by the electrical panel.
Surge Protection:
2kV
Note:
All values are typical (tolerance +/- 10%)
Optical
NEMA Type:
NEMA Beam Spread of 7H x 7V
LED Characteristics
LEDs:
Long-life, high-efficacy, surface-mount LEDs
Color Uniformity:
RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.
Performance
Lifespan:
50,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations
Construction
IP Rating:
Ingress protection rating of IP65 for dust and water
IP Rating:
Ingress protection rating of IP65 for dust and water
