RAB X34XXLT LED Floodlight 160/140/120W, 17458-24168 Lumens, Trunnion Mount, 3000K/4000K/5000K Color Temperature, 120/277V, Bronze

Field Adjustable Light Output:

Suitable for wet locations. Suitable for mounting within 4 ft of the ground.

RAB LED luminaires and LED components have been tested by an independent laboratory in accordance with IESNA LM-79 and LM-80.

Ingress protection rating of IP65 for dust and water

This product is a product of Cambodia and a "designated country" end product that complies with the Trade Agreements Act

This product is listed by Design Lights Consortium (DLC) as an ultra-efficient premium product that qualifies for the highest tier of rebates from DLC Member Utilities. Designed to meet DLC 5.1 requirements.

Constant Current, Class 1, 120-277V, 50/60 Hz

Driver includes dimming control wiring for 0-10V dimming systems. Requires separate 0-10V DC dimming circuit. Dims down to 10%.

160W: 3.1% at 120V, 5.9% at 277V

160W:99.8% at 120V, 95.2% at 277V

Integrated photocell included with on/off switch

NEMA Beam Spread 7H x 7V

Long-life, high-efficacy, surface-mount LEDs

RAB's range of Correlated Color Temperature follows the guidelines of the American National Standard for Specifications for the Chromaticity of Solid State Lighting (SSL) Products, ANSI C78.377-2017.

100,000-Hour LED lifespan based on IES LM-80 results and TM-21 calculations

160W: Replaces up to 750W Metal Halide (MH) or 400W High Pressure Sodium (HPS)

The minimum starting temperature is -40°F (-40°C)

Suitable for use in up to 104°F (40°C)

Die-cast aluminum

-90° to +90°

Tempered glass

Polyethylene Terephthalate (PET)

EPA = 1.1

Formulated for high durability and long-lasting color

Mercury and UV free. RoHS-compliant components.

Trunnion with tilt angle in 30° increments

The RAB 5-year, limited warranty covers light output, driver performance and paint finish. RAB's warranty is subject to all terms and conditions found at rablighting.com/warranty.
