PRODUCT DESCRIPTION
The APELSQ is an UL 924 listed emergency light with a minimum of 90 minutes of run time. Key features include LED heads, a no maintenance
The APELSQ is an UL 924 listed emergency light with a minimum of 90 minutes of run time. Key features include LED heads, a no maintenance
nickel cadmium battery and a five year fixture warranty. The square LED heads are fully adjustable to maximize design flexibility while the compact form factor optimizes aesthetics. The universal j-box mounting pattern and snap fit housing construction significantly reduce installation time.
PRODUCT SPECIFICATIONS
Electrical
Housing ConstructionPRODUCT SPECIFICATIONS
Electrical
- Dual Voltage Input 120/277VAC, 60Hz
- Line-latching
- Brownout circuit
- Low Voltage Disconnect
- Overload/Short Circuit Protection
- Test Switch/Power connector facilitates installation
- 3.6V, 1.0W DC Long Lasting LED Heads
- All components are injectionmolded, color stable, high impact thermoplastic material
- Designer textured finish standard
- Suitable for wall or ceiling mount applications
- Universal J-box mounting pattern
- Keyhole mounting slots
- Available in white
- Sealed nickel cadmium
- Maintenance-free, long-life
- Full recharge time: 24 hrs (max.)
- Not for sale in California
- UL 924 Damp Location Listed
- Life Safety NFPA 101
- NEC/OSHA
- Most State and Local Codes
- Operating temperature range 10 degreeC to 40 degreeC
- Long Life LED Emergency Heads
- Two heads standard
- Fully adjustable
- High impact thermoplastic
- Matches housing finish
- Five-year warranty
- Seven-year prorated battery warranty
