Sure Lites APCH7RGSQ30 All-Pro Square Headed Combination Exit and Emergency Light, Red Green Selectable, Nickel Cadmium Battery, Remote Capacity, White Finish
Sure Lites APCH7RGSQ30 All-Pro Square Headed Combination Exit and Emergency Light, Red Green Selectable, Nickel Cadmium Battery, Remote Capacity, White Finish
Regular price
Price:
$117.15
Regular price
Price:
Sale price
$117.15
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT SPECIFICATIONS
Illumination Source Data
Illumination Source Data
- Long life LEDs provide uniform, diffused illumination for the EXIT face
- RG models have field selectable red or green LEDs
- LED sources are brighter in emergency mode
- 3.6V, 1.5W Long life LED heads provide up to 30 feet egress coverage
- Dual voltage input 120/277VAC, 60Hz
- Line-latching
- Solid-state voltage limited charger
- Solid-state switching
- Overload/short circuit protection
- Test switch / power indicator light
- High power remote option available capable of running two additional APWR 3.6V, 0.78W remote emergency lights
- All components are injection molded, color stable, high impact, 5VA flame resistant, thermoplastic housing
- UV stabilized to resist discoloration due to age and ultraviolet radiation
- APC7RGSQ30/APCH7RGSQ30 series LEDs and lens panels are field selectable red or green. APC7RGSQ30/APCH7RGSQ30 series come with LEDs set to "red" with red inserts installed. The APC7RGSQ30/APCH7RGSQ30 series and can be easily converted to "green" LEDs and inserts in the field.
- Available in white or black textured finish
- Components are of snap-fit construction to facilitate under 5-minute installation
- Reinforcing ribs throughout to provide maximum strength connections
- Molded-in wireways facilitate internal wire routing and connections
- All components including battery and electronics are located inside the exit housing
- Snap-out or snap-in chevron directional indicators have full 3/4" stroke
- Universal exits can be field configured as single face or double face
- Snap-fit canopy with mounting screws included with all exits
- Exit can be ceiling, wall, or end mounted
- Universal J-box mounting pattern
- Operating temperature range 0°C to 50°C
- 120/277 VAC, voltage regulated solid-state charger
- High charge rate immediately following power restoration of AC current after a power failure
- Charge circuit reacts to the condition of the battery and regulates the charging process in order to maintain peak battery capacity and maximize battery life
- Solid-state construction recharges the battery following a power failure in accordance with UL 924
- Switch located on the side of the exit permits the activation of the emergency circuit for complete operational systems check
- Indicator light provides visual assurance that the AC power is on
- AC activated load switch prevents lamps from turning on during installation to a non-energized AC circuit
- Eliminates need of contractor to return to job site to connect batteries when building’s main power is turned on
- Sealed nickel cadmium
- Maintenance free, long life
- Full recharge time: 24 hrs (max.)
- UL 924 Listed
- UL Damp Location Listed
- Life Safety NFPA 101
- NEC/OSHA
- California Energy Code compliant
Limited Warranty
- Five-year limited warranty
