Sure Lites APX7RGSAL All-Pro LED Exit Sign with SALIDA Face, Red Green Selectable, AC Only, White Finish
Sure Lites APX7RGSAL All-Pro LED Exit Sign with SALIDA Face, Red Green Selectable, AC Only, White Finish
Regular price
Price:
$96.03
Regular price
Price:
Sale price
$96.03
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT SPECIFICATIONS
Illumination Source Data
Illumination Source Data
- Long life LEDs provide uniform, diffuse illumination for the SALIDA face
- RG models have field selectable red or green LEDs
- Battery backup LED sources are brighter in emergency mode
- LED sources provide low operating costs and no maintenance
- Field selectable red and green letters (units are shipped pre-configured with red letters and can easily be converted to green letters in the field).
- Dual Voltage Input 120/277VAC 60Hz
- Solid-State voltage limited charger
- Brownout circuit
- Test switch / Power indicator light
- All components are injection molded, color stable, high impact, 5VA flame resistant, thermoplastic materials
- UV stabilized to resist discoloration due to age and ultraviolet radiation
- APX7RGSAL LEDs and lens panels are field selectable red or green. The APX7RGSAL exits come with LEDs set to ""red" with red inserts installed. The exits can be easily converted to "green" LEDs and inserts in the field.
- Available in a white finish
- Components are of snap-fit construction to facilitate under 5-minute installation
- Reinforcing ribs throughout to provide maximum strength connections
- All components including battery and electronics are located inside the exit housing
- Snap-out or snap-in chevron directional indicators have full 3/4" stroke
- Universal exits can be field configured as single face or double face
- Snap-fit canopy with mounting screws included with all exits
- Exit can be ceiling, wall, or end mounted
- Universal J-box mounting pattern
- 120/277 VAC, voltage regulated solid-state charger
- High charge rate immediately following power restoration of AC current after a power failure
- Charge circuit reacts to the condition of the battery and regulates the charging process in order to maintain peak battery capacity and maximize battery life
- Solid-state construction recharges the battery following a power failure in accordance with UL 924
- Monitors the flow of AC current
- Activates the emergency lighting system when a predetermined reduction/dip of AC power occurs (a dip in voltage will cause most ballasted products to extinguish, causing loss of normal lighting even though a total power failure has not occurred)
- Switch located on the bottom of the exit permits the activation of the emergency circuit for complete operational systems check
- Indicator light provides visual assurance that the AC power is on
- Sealed nickel cadmium
- Maintenance-free, long-life
- Full recharge time: 24 hrs (max.)
- UL 924 Listed
- UL Damp Location Listed
- Life Safety NFPA 101
- NEC/OSHA
- Operating temperature range 10 °C to 40 °C
- California Energy Code compliant
- Norma Oficial Mexicana (NOM) Certified
- AC LED: Long life LED lamps provide uniform diffused illumination
- DC: LED DC lamps
- Five-year limited warranty
- Seven-year prorated battery limited warranty
