Sure Lites CX71WHSD Surface Mount LED Exit and Emergency Light, AC Powered with Battery Back Up, Single Face, White Housing, Self-Diagnostics

Sure Lites CX71WHSD Surface Mount LED Exit and Emergency Light, AC Powered with Battery Back Up, Single Face, White Housing, Self-Diagnostics

Price: $269.45
Price: $269.45

MODEL: Sure-Lites-CX71WHSD
Add To Wishlist
Request a Quote
Ordering a Large Quantity? Request a quote
View full details

description

PRODUCT FAMILY SPECIFICATIONS
Electrical
General Features
  • Field selectable red and green sign capability standard on all units (units shipped red, field convert to green with supplied parts)
  • Dual Voltage Input 120/277 VAC,60Hz
AC Only
  • Optional 2C (Two circuit, FTBR) available in 120/277 VAC in standard and emergency operation. 2C models does not accept two hot circuits.
Self Powered (Self-powered units have battery backup to provide 90 minutes of run time when A/C power is lost. Units must be connected to A/C power for standard operation.)
  • Sure-Lites EZ Key patented external battery disconnect feature – prevents unnecessary battery drainage, saves on installation time
  • Solid-state Voltage Limited Charger
  • Brownout Circuit
  • Low-Voltage Disconnect
  • Test Switch/Power Indicator Light
  • Standard 24 hour recharge time (max)
  • Self-Diagnostic feature standard for CX7 self-powered series
Housing Construction
  • Die cast aluminum housing
  • Injection molded, color stable, high impact polycarbonate faces
  • Die cast canopy included (for mounting convenience only, no electrical components in canopy)
  • Universal pattern knockouts on rear of single face housing for direct mounting to junction box
  • Knockout provided on housing for surface attachment
  • Exit can be universally mounted: ceiling, wall or end
  • Choice of three finishes: black housing with brushed aluminum face, white housing with white face or black housing with black face
  • NFPA 101 compliant knockout chevrons allow quick conversion to directional signs
  • Single and double faced signs available, order separately
Code Compliance
  • UL 924 Listed
  • UL Damp Location (0-40° C)
  • Life Safety NFPA 101
  • NEC/OSHA
  • Most State and Local Codes
  • Suitable for Floor Proximity Installation
  • UL Listed for 2C (FTBR)
Lamp Data
  • AC LED: Red and green LED lamps provide uniform diffused illumination
  • DC: Red and green LED DC lamps (Brighter in emergency mode)
Warranty
  • Exit - 5 year
  • Battery: 7-Year pro-rata
