Sure Lites SEL70BKSD LED Emergency Light, 70 Ft Coverage, Black Color, Self-Diagnostics
Sure Lites SEL70BKSD LED Emergency Light, 70 Ft Coverage, Black Color, Self-Diagnostics
Regular price
Price:
$189.26
Regular price
Price:
Sale price
$189.26
Unit price
per
Ordering a Large Quantity?
Request a quote
description
PRODUCT FAMILY SPECIFICATIONS
Regulatory
Regulatory
- Listed to UL 924 for Field Installation in US and Canada (Indoor and Damp)
- NFPA 70 (National Electrical Code)
- NFPA 101 (Life Safety Code)
- CEC Title 20 Compliant
Emergency Output Lumens (lamp heads)
- Fixture spacing - see page 3
- 90 Minutes
AC Input Voltage
- Universal input 120 - 277 VAC, 50/60 Hz AC Input Current (max)
- 120 Vac = 55 mA
- 277 Vac = 35 mA
Recharge Time
- 24 Hours for all standard products and 36 hours for products with remote battery (SEL30R4 and SEL70R5) capacity
Charging Indicator Light / Test Switch
- Integrated, Bi-color LED Test Switch
- 50° F to 104° F (10° C to 40° C)
Battery
- Integral Maintenance-Free Lithium-Ion Battery
Construction
- White thermoplastic housing
- UL 94 5VA Flame Rated, UV stable
- Contractor friendly snap together design
- Electronics and battery contained within housing
Installation
- Wall and Ceiling mounting
- Backplate keyhole slots are easily removable
- Knockouts for securing to a 3” or 4” j-box
Lamps
- Two (2) 2.5W LED lamp sources (5000K)
- Lampheads adjustable
Surge Rating
- NEMA/ANSI C82.77-5-2017 100kHz Ring Wave (w/t 30Ω)
- >2.5kV Differential (L-N)
- >2.5kV Common (L-G, N-G, L&N-G)
Warranty
- 5 Years (not pro-rata)
Download PDF Specification Share your knowledge of this product. Be the first to write a review »
