Wattstopper BZ-50RC Power Pack, 120-277V, 50/60Hz, 24VDC, 225mA, RJ45 Connector
Wattstopper BZ-50RC Power Pack, 120-277V, 50/60Hz, 24VDC, 225mA, RJ45 Connector
Regular price
Price:
$41.02
Regular price
Price:
Sale price
$41.02
Unit price
per
MODEL: Wattstopper-BZ-50RC
Usually Ships in 3-5 business days. Urgent Project? Contact Us
Couldn't load pickup availability
Ordering a large quantity?Request a quote
description
PRODUCT SPECIFICATIONS
The BZ-50 Universal Voltage Power Pack provides 24 VDC operating voltage to Wattstopper’s low-voltage occupancy sensors. This device is constructed with environmentally friendly materials and is RoHS-compliant.
PRODUCT FEATURES
The BZ-50 Universal Voltage Power Pack provides 24 VDC operating voltage to Wattstopper’s low-voltage occupancy sensors. This device is constructed with environmentally friendly materials and is RoHS-compliant.
PRODUCT FEATURES
- Self-contained power supply relay system
- Efficient switching power supply providing optimized current output based on number of sensors
- LED indicates status of relay or if there is a low-voltage overcurrent
- The product meets the materials restrictions of RoHS
- Zero crossing circuitry for reliability and increased product life
- UL 2043 plenum rated for cost-effective installation
- 1/2" snap-in nipple attaches to standard electrical enclosures through 1/2" knockouts
PRODUCT SPECIFICATIONS
- 20/277VAC, 230/240V (single phase), 50/60Hz voltage input
- Load Requirements
- Ballast, Incandescent: 20amp @120/277VAC
- Eballast: 16amp @277VAC
- Motor: 1HP @120/240VAC
- Output: 225mA @24VDC (with relay connected)
- Connection: BZ-50RC with RJ45 connections
- UL-rated 94 V-O gray plastic enclosure
- Dimensions: 1.6 x 2.75" x 1.6" (40.6mm x 69.9mm x 40.6mm) H x W x D with a 1/2" (12.7mm) snap-in nipple
- UL and cUL listed
- Five year warranty
